Braumers Home station EV Charger 32A Type2 22KW
Model: BREV-HS32AT2-3PH
Unique benefits:
SNCP App for managing the Charging Station. Android, IPhone
CP Tool App for connecting the Station to cloud. Android , IPhone
Built-in load management.
Built-in depreciation rates protection.
Product Introduction
1.1 Follow the standards
Type 2: Meet European standards, IEC 61851 / IEC 62196 / CE, IEC 62955(optional).
Application range
AC charging posts are suitable for providing AC power to electric vehicles with on-board chargers.
AC charging stations can be easily and quickly installed in various public, internal and internal parking spaces of the community, and can also be installed in various large, medium and small electric vehicle charging stations.
1.2 Main Technical Parameters
| Basic Info | Item | Technology Index | Remarks |
| Model | SK-T6ACE032A3P | BREV-HS32AT2- 3PH | |
| Electrical Parameters | Rated Input Voltage | AC380V | 3 Phases |
| Max. Power | 22KW | ||
| Rated Working Current | 32A | 6 mm2 wire | |
| Input Frequency | 50HZ | ||
| Rated Output Voltage | AC380V | 3 phases | |
| Rated Output Current | 32A (8A/16A/24A/32A Current Switching) | ||
| Standby Power | <6W | ||
| Environment index | Application Scenes | Indoor/Outdoor | |
| Working Temperature | -30℃~+55℃ | ||
| Working Humidity | 5%~95% without Condensation | ||
| Working Elevation | <2000m | ||
| Protection Grade | IP55 | ||
| Cooling Method | Natural Cooling | ||
| MTBF | 50,000 Hours | ||
| Shell structure | Material | ABS+PC | |
| Dimension | 345*211*122mm(L*W*D) | ||
| Installations | Wall-mounted / standing pole | ||
| Activate Method | ON/OFF by swiping card (3pcs) | ||
| Net. Weight | 6.0kgs | Type 2 with 5M cable | |
| Security design | Over voltage protection, Under voltage protection, Overload protection, | ||
| Short-circuit protection, Grounding protection, Lightning protection, | |||
| Current leakage Type A protection (TypeA+DC6mA Optional) | |||
The AC charging station has the following features:
- Safe and stable: The wall-mounted/column AC charging station provides reliable electrical safety protection function. It can be anti-theft, dust-proof, waterproof and stable in operation, ensuring long-term reliable operation. Meets the outdoor IP54 protection;
- System integration: The charging function, man-machine operation, safety protection and other functions of the whole charging station are highly integrated. The system has simple structure, is conducive to production, and is stable and reliable;
- Simple operation: Friendly man-machine interface and simple operation;
- Small floor area and convenient installation: small floor area and high space utilization rate, which is convenient for installation and use in places with tight land.
- Abnormal connection protection: The charging station can judge whether the connection between the station and the vehicle is correct. If the connection is correct, the charging can be started. When the connection between the charging station and the vehicle is abnormal, the charging station shall stop charging immediately to ensure personal safety and charging safety;
- Multiple protection: The charging station has over-voltage / under-voltage and over-current
protection function, when the charging voltage / current is higher than the over-voltage / over-current protection setting or lower than the under-voltage protection setting, the charging station stops charging to protect the charging device. The charging station also has short circuit protection function.
7) DC 6mA leakage protection (optional): Customer can select built-in DC 6mA leakage protection;
8) Multiple protection: moisture-proof, mildew proof, salt proof and rust proof. It can work normally in a humid and salty environment;
9) Beautiful appearance: the overall design is simple and generous, and the theme mask can be customized. The style is colorful;
10) According to special requirements, it can be compatible with new and old standard electric vehicle charging.
